CM-2018 Clamp open 28mm, AC DC Max 800A, LPF, LoZ V, True RMS, NCV (clamp + red test lead), Capacitance, Frequency, Temperature tests, Backlight, Clamp lighting function.
CM-2018 clamp meter, available to DC voltage, AC voltage, DC current, AC current, LPF, LoZ V, resistance, capacitance, frequency, non-contact voltage (clamp + red test lead 2 detecting ways), temperature, diode and continuity tests; Designed with unit symbol and backlight display, data hold, clamp lighting, auto ranging switch, auto power off and alarm functions.
6000 digits display
Technic Data:
Special Function:
|
Basic function |
Range |
Accuracy |
|
DCV |
600mV/6V/60V/600V |
±(0.5%+3) |
|
LoZ 0V~600V |
±(2.0%+10) |
|
|
ACV |
6V/60V/600V |
±(0.8%+5) |
|
LPF 0V ~ 600V |
±(4.0%+8) |
|
|
LoZ 0V ~ 600V |
±(2.0%+10) |
|
|
DCA |
60A/600A/800A |
±(1.5%+5) |
|
ACA |
60A/600A/800A |
±(1.5%+5) |
|
Resistance |
600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ |
±(0.8%+1) |
|
Capacitance |
6nF/60nF/600nF/6uF/60uF/600uF/6MF/60MF |
±(2.5%+5) |
|
Frequency |
10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz |
±(0.1%+3) |
|
Temperature |
(-40 to 1000 )℃, (-40 to 1832 ) ℉ |
±(1.0%+5) |
Special Function:
|
Model |
CM-2018 |
|
Diode test |
√ |
|
Continuity test |
Less than 50Ω |
|
LoZ V function |
√ |
|
Low battery indicator |
Approx. less than 2.6 V |
|
Data hold |
√ |
|
NCV |
√ (2 detecting way) |
|
Auto power off |
About 15 minutes |
|
True RMS test |
√ |
|
LPF function |
√ |
|
Function protection |
√ |
|
Clamp light function |
√ |
|
Backlight display |
√ |
|
Input impedance |
10MΩ |
|
Sampling rate |
3 times/s |
|
AC frequency response |
40-2kHz |
|
Operation method |
Auto or manual range |
|
Max display |
6000 |
|
Clamp opens |
28mm |
|
Battery |
3V (2*AAA battery) |
