LX-1336B Screen Brightness Digital Illuminometer, Color Temperature 2856K standard calibration, Data hold, Intelligent Auto Power OFF.
LX-1336B screen brightness meter is mainly used to test the luminous brightness of various backlights such as televisions, computers, and mobile phone screens. It can test whether the light intensity of each distribution point of the effective area of various backlights is uniform, test the brightness of televisions, computers, and mobile phone screens, prevent eye damage, and play a certain role in eye protection for students and children.
Technical Data:
|
Range |
Accuracy |
Result |
|
20 cd |
±5% rdg ± 10. |
Reading |
|
200 cd |
Reading |
|
|
2,000 cd |
reading |
|
|
20,000 cd |
10×reading |
Special Function:
|
Model |
LX 1336B |
|
Repeatability |
±2% |
|
Temperature characteristic |
± 0.1%/℃ |
|
Auto zero-adjustment |
√ |
|
Data Hold |
√ |
|
Low battery indication |
√ |
|
Auto power off |
√ |
|
Sensor |
Photo diode and filter |
|
Sampling rate |
2 times/second |
|
Resolution |
0.01 cd |
|
Operation way |
Manual range |
|
Max. Display |
1999 |
|
LCD size |
67×40mm |
|
Battery |
9V (6F22) |
